BluePrint Engines Chev 400 Crate Engine Dressed With Sniper 2 # BP4002CTF

Product image 1
1 / 4

BluePrint Engines Chev 400 Crate Engine Dressed With Sniper 2 # BP4002CTF

GM Small Block Compatible 400 c.i. Engine - 500 Horsepower - Base Dressed - Fuel Injected

SKU: BP4002CTF

Horsepower & Torque: 500 Horsepower / 510 ft. lbs. Torque

Cylinder Heads: BluePrint Engines Aluminum Cylinder Heads

Compression Ratio: 10.3:1

Camshaft: Hydraulic Roller Cam - .555 Intake / .576 Exhaust Lift and 236 Intake / 242 Exhaust Duration @.050-1100 LSA

Pistons: Forged

Crankshaft: Forged Crank - 3.750" Stroke and 5.700" Rods

Description:

  • Horsepower & Torque: 500 Horsepower / 510 FT. LBS. Torque
  • Compression Ratio: 10.3:1
  • BluePrint Engines Aluminum Heads
  • BluePrint Engines Hydraulic Roller Cam
  • BluePrint Engines Forged Crank
  • BluePrint Engines Forged Pistons

Block:

  • BluePrint Engines High Strength Cast Iron Block
  • Manufactured and Machined in the USA!
  • Drilled and Tapped for Clutch Linkage
  • Mech Fuel Pump Provision: Yes
  • Passenger Side Dipstick
  • 1-Piece Rear Main Seal
  • 4-Bolt Main
  • 4.125" Bore

Rotating Assembly:

  • BluePrint Forged Crankshaft
  • 3.750" Stroke
  • 5.700" Connecting Rods w/ 150,000 PSI Bolts
  • Forged Pistons
  • Internally Balanced Front - Externally Balanced Rear

Cylinder Heads:

  • BluePrint Aluminum Cylinder Heads - HP8103
  • 64cc Chamber
  • 2.08" Intake /1.60" Exhaust Valves
  • 220cc Intake / 67cc Exhaust Runners

Cam Specs:

  • Hydraulic Roller
  • .555 Intake / .576 Exhaust Lift
  • 236 Intake / 242 Exhaust Duration
  • @ .050-110 Degree Lobe Separation

Ignition Timing:

  • 10-160 Initial and Total Timing 32-340 at 3500 RPM

Also Includes:

  • Intake Manifold Dual Plane, Satin Aluminum - BPP350VINT
  • Holley Sniper 2 EFI System - BPP550-510-3XX
  • HEI Ready Run Distributor - BPP350RBK
  • Valve Covers - BPP9518
  • Timing Cover
  • Oil Pan

GM Small Block Compatible 400 c.i. Engine - 500 Horsepower - Base Dressed - Fuel Injected

SKU: BP4002CTF

Horsepower & Torque: 500 Horsepower / 510 ft. lbs. Torque

Cylinder Heads: BluePrint Engines Aluminum Cylinder Heads

Compression Ratio: 10.3:1

Camshaft: Hydraulic Roller Cam - .555 Intake / .576 Exhaust Lift and 236 Intake / 242 Exhaust Duration @.050-1100 LSA

Pistons: Forged

Crankshaft: Forged Crank - 3.750" Stroke and 5.700" Rods

Description:

  • Horsepower & Torque: 500 Horsepower / 510 FT. LBS. Torque
  • Compression Ratio: 10.3:1
  • BluePrint Engines Aluminum Heads
  • BluePrint Engines Hydraulic Roller Cam
  • BluePrint Engines Forged Crank
  • BluePrint Engines Forged Pistons

Block:

  • BluePrint Engines High Strength Cast Iron Block
  • Manufactured and Machined in the USA!
  • Drilled and Tapped for Clutch Linkage
  • Mech Fuel Pump Provision: Yes
  • Passenger Side Dipstick
  • 1-Piece Rear Main Seal
  • 4-Bolt Main
  • 4.125" Bore

Rotating Assembly:

  • BluePrint Forged Crankshaft
  • 3.750" Stroke
  • 5.700" Connecting Rods w/ 150,000 PSI Bolts
  • Forged Pistons
  • Internally Balanced Front - Externally Balanced Rear

Cylinder Heads:

  • BluePrint Aluminum Cylinder Heads - HP8103
  • 64cc Chamber
  • 2.08" Intake /1.60" Exhaust Valves
  • 220cc Intake / 67cc Exhaust Runners

Cam Specs:

  • Hydraulic Roller
  • .555 Intake / .576 Exhaust Lift
  • 236 Intake / 242 Exhaust Duration
  • @ .050-110 Degree Lobe Separation

Ignition Timing:

  • 10-160 Initial and Total Timing 32-340 at 3500 RPM

Also Includes:

  • Intake Manifold Dual Plane, Satin Aluminum - BPP350VINT
  • Holley Sniper 2 EFI System - BPP550-510-3XX
  • HEI Ready Run Distributor - BPP350RBK
  • Valve Covers - BPP9518
  • Timing Cover
  • Oil Pan
$4,556.48

Original: $13,018.51

-65%
BluePrint Engines Chev 400 Crate Engine Dressed With Sniper 2 # BP4002CTF—

$13,018.51

$4,556.48

Description

GM Small Block Compatible 400 c.i. Engine - 500 Horsepower - Base Dressed - Fuel Injected

SKU: BP4002CTF

Horsepower & Torque: 500 Horsepower / 510 ft. lbs. Torque

Cylinder Heads: BluePrint Engines Aluminum Cylinder Heads

Compression Ratio: 10.3:1

Camshaft: Hydraulic Roller Cam - .555 Intake / .576 Exhaust Lift and 236 Intake / 242 Exhaust Duration @.050-1100 LSA

Pistons: Forged

Crankshaft: Forged Crank - 3.750" Stroke and 5.700" Rods

Description:

  • Horsepower & Torque: 500 Horsepower / 510 FT. LBS. Torque
  • Compression Ratio: 10.3:1
  • BluePrint Engines Aluminum Heads
  • BluePrint Engines Hydraulic Roller Cam
  • BluePrint Engines Forged Crank
  • BluePrint Engines Forged Pistons

Block:

  • BluePrint Engines High Strength Cast Iron Block
  • Manufactured and Machined in the USA!
  • Drilled and Tapped for Clutch Linkage
  • Mech Fuel Pump Provision: Yes
  • Passenger Side Dipstick
  • 1-Piece Rear Main Seal
  • 4-Bolt Main
  • 4.125" Bore

Rotating Assembly:

  • BluePrint Forged Crankshaft
  • 3.750" Stroke
  • 5.700" Connecting Rods w/ 150,000 PSI Bolts
  • Forged Pistons
  • Internally Balanced Front - Externally Balanced Rear

Cylinder Heads:

  • BluePrint Aluminum Cylinder Heads - HP8103
  • 64cc Chamber
  • 2.08" Intake /1.60" Exhaust Valves
  • 220cc Intake / 67cc Exhaust Runners

Cam Specs:

  • Hydraulic Roller
  • .555 Intake / .576 Exhaust Lift
  • 236 Intake / 242 Exhaust Duration
  • @ .050-110 Degree Lobe Separation

Ignition Timing:

  • 10-160 Initial and Total Timing 32-340 at 3500 RPM

Also Includes:

  • Intake Manifold Dual Plane, Satin Aluminum - BPP350VINT
  • Holley Sniper 2 EFI System - BPP550-510-3XX
  • HEI Ready Run Distributor - BPP350RBK
  • Valve Covers - BPP9518
  • Timing Cover
  • Oil Pan
